Learn the Robocop
Build a simple cardboard "Robocop" costume with LED eyes and a motorized arm using safe craft tools and basic circuits to learn robotics.
Step-by-step guide to build a cardboard Robocop costume
Step 1
Gather all the materials from the list and lay them out on a clean table.
Step 2
Measure your head circumference with a soft tape or a string.
Step 3
Mark that length on cardboard with a ruler and pencil to draw the helmet band rectangle.
Step 4
Cut out the helmet band and a faceplate shape from the cardboard using scissors or a craft knife with adult help.
Step 5
Curve the cardboard band into a circle to match your head measurement.
Step 6
Glue the band ends together to form the helmet base.
Step 7
Glue the faceplate to the front of the helmet base.
Step 8
Cut two small eye holes in the faceplate where you want the LED eyes to sit.
Step 9
Push each LED through an eye hole so the LED bulb faces outward and the leads point inside the helmet.
Step 10
Attach a 220Ω resistor to the positive lead of each LED and secure each joint with tape or solder with adult help.
Step 11
Connect each LED negative lead to the battery holder negative wire and connect each resistor end to the battery holder positive wire then switch on briefly to test the LED eyes.
Step 12
Glue the small DC motor to a cardboard chest plate and glue a bottle cap or cardboard disk to the motor shaft to act as a cam.
Step 13
Cut a cardboard arm and add a plastic straw or wooden skewer as its hinge then attach the arm to the bottle cap cam so the arm will move when the motor spins.
Step 14
Connect the motor wires to the battery holder and test the moving arm then decorate the helmet and chest plate with coloring materials.
Step 15
Share your finished Robocop costume on DIY.org
Help!?
What can I use if I don't have a soft measuring tape, a 220Ω resistor, or a small DC motor?
Use a piece of string to measure head circumference (step 2); for the LEDs you can substitute pre-wired battery LED craft lights or a single 330–470Ω resistor in series instead of a 220Ω (LED/resistor steps); and swap the small DC motor for a pager or toy motor glued to the cardboard chest plate to drive the bottle cap cam (motor and bottle cap step).
My LED eyes won't light and the arm motor doesn't move — what should I check?
Check LED polarity and that each 220Ω resistor is on the LED positive lead and connected to the battery holder positive as in the LED test step, make sure the battery orientation and tape/solder joints are secure and the switch is on, and verify the motor wires have good contact, the battery has enough voltage, and the bottle cap cam and straw/skewer hinge aren't glued or jammed so the arm can move (motor and hinge steps).
How can I adapt the project for younger or older kids?
For younger children have an adult pre-cut the helmet band, faceplate and chest plate and use stick-on LED lights or pre-wired snap LEDs with tape for safety while they decorate, and for older kids let them use a craft knife and solder the LED/resistor joints, design a better cam on the motor shaft, or add a switch or microcontroller for extra features.
How can I enhance or personalize the Robocop costume after finishing the basic build?
Add a small slide or toggle switch inline with the battery holder positive wire to control the LED eyes and motor from the test step, paint or cover the cardboard with metallic foil, glue foam padding inside the helmet for comfort, replace the bottle cap with a larger offset disc for stronger arm motion, or add an Arduino/blink circuit to make the LEDs flash in patterns.
